Tubular Vibratory Conveyors

Tubular Vibratory Conveyors

Our tubular vibratory conveyors are simple, cost-effective and offer clean and gentle material handling. Tubular vibratory conveyors from Gough Econ have no moving parts; only contra-rotating motors, making this simple unit both user-friendly and environmentally safe. Because of their simple design, installation costs for our tubular vibratory conveyors are minimized.

General Details

Simplicity

  • No moving parts – only contra-rotating motors.
  • The simple design makes this unit environmentally safe and user friendly.

Gentle & Clean Handling System

  • Product is contained within the tube to eliminate dusting or spillage.
  • Low vibration ensures product integrity during transfer.

Minimal Space Requirements

  • Unit can be mounted overhead to conserve floor space.
  • Units can be mounted on an incline or decline dependent upon product density and flow characteristics.

Cost Effective Conveying Solution

  • Motors consume very low power for operation.
  • Installation costs are kept to a minimum due to the simple design.
Technical Data

tubconvey-2

Documents

For additional information on tubular conveyors, click here to download our two-page flyer (125 kilobytes).
It contains general information as well as technical data and dimensions of standard units with tubes ranging from 6″ to 12″ in diameter.
